🧪 Day 01: Lab 1 & Lab 2 – AWS EC2 and Docker ECR Deployment....
Overview
This lab series focuses on foundational cloud and DevOps skills using AWS and Docker. The goal is to understand how to provision and configure cloud infrastructure, containerize an application, and manage container images using AWS Elastic Container Registry (ECR).
Lab 1: Setting up an AWS EC2 Instance for Docker
Objective
Learn how to provision and configure an AWS EC2 instance suitable for Docker deployments.
Tasks
- Launch an EC2 instance
- SSH into the instance
- Install Docker
Task 1: Launch an EC2 Instance
Use the AWS CLI to launch an EC2 instance. This step includes choosing an Amazon Machine Image (AMI), selecting an instance type, and configuring security groups and key pairs.
Task 2: SSH into the Instance
Once the instance is running, connect via SSH:
ssh -i "your-key-pair.pem" ubuntu@your-ec2-public-ip
Replace your-key-pair.pem with your private key file and your-ec2-public-ip with your EC2 public IP address.
Task 3: Install Docker
Run the following commands to install Docker on your EC2 instance:
# Update the package database
sudo apt update -y
# Install Docker
sudo apt install docker.io -y
# Start and enable Docker
sudo systemctl start docker
sudo systemctl enable docker
Docker should now be installed and running on your EC2 instance.
Concepts Covered…💪🏻
- AWS EC2 (Elastic Compute Cloud): Virtual servers for scalable compute in the cloud.
- SSH (Secure Shell): Secure protocol for remote server access.
- Docker: Platform for building, deploying, and managing containerized applications.
Outcome…👇
By completing this lab, you gain hands-on experience in provisioning cloud instances, establishing secure connections, and preparing an environment for Docker-based deployments.
Jump to the Next one…
Lab 2: Building and Pushing a Docker Image to AWS ECR
Objective
Build a Docker image and push it to AWS Elastic Container Registry (ECR) for secure storage and deployment.
Tasks
- Install Docker
- Install AWS CLI
- Create a Dockerfile
- Build the Docker image
- Authenticate AWS ECR
- Create an ECR repository
- Tag the Docker image
- Push the Docker image to ECR
- Verify the image in ECR
Task 1: Install Docker
Install Docker on your local machine or Ec2 if it’s not already installed.
Check out the link Download Docker
Task 2: Create a Dockerfile
Create a Dockerfile in your project directory or use this repo Project Repo.
# Step 1: Build React app
FROM node:20-alpine AS build
WORKDIR /app
COPY package.json package-lock.json ./
RUN npm install
COPY . .
RUN npm run build
# Step 2: Serve with NGINX
FROM nginx:alpine
COPY --from=build /app/build /usr/share/nginx/html
EXPOSE 80
CMD ["nginx", "-g", "daemon off;"]
Task 3: Build the Docker Image..
docker build -t myapp:latest .
Task 4: Authenticate to AWS ECR
Authenticate Docker with your AWS account:
aws ecr get-login-password --region <your-region> | docker login --username AWS --password-stdin <your-account-id>.dkr.ecr.<your-region>.amazonaws.com
Task 5: Create an ECR Repository
Create a new repository in AWS ECR to store your Docker image.
Task 6: Tag the Docker Image
docker tag myapp:latest <your-account-id>.dkr.ecr.<your-region>.amazonaws.com/myapp:latest
Task 7: Push the Docker Image to ECR
docker push <your-account-id>.dkr.ecr.<your-region>.amazonaws.com/myapp:latest
Task 8: Verify the Image in ECR
Check your AWS ECR console to verify the image upload.
Outcome
By completing this lab, you learned how to:
- Build custom Docker images
- Authenticate and interact with AWS ECR
- Manage container images for deployment on AWS services like ECS and Fargate
Final Thoughts…💭
These labs provided hands-on experience with fundamental DevOps workflows — from provisioning servers and securing access to containerizing applications and managing images in the cloud. The next step is to deploy these containers using Amazon ECS and AWS Fargate for scalable, managed orchestration.
